Joint imaging

By

Dr. Firas Abdullah


background image

Aims of our lecture:

Radiological signs of  joint disease

Diagnosis of arthritis

Different types of arthritis

Other joint pathology

MRI of knee and shoulder


background image

background image

Plain film signs of joint disease

Joint space narrowing

: due to destruction of articular

cartilage. It occurs in practically all forms of joint

disease, except avascular necrosis.

Soft tissue swelling

: a feature of inflammatory, and

particularly infective arthritis. Also can be seen in

gouty tophi.

Osteoporosis

: painful conditions and underuse of the

bones. E.g. rheumatoid and tuberculous arthritis.


background image

Articular erosions

: destruction of the articular cortex and

the adjacent trabecular bone

Causes

:

1- Inflammatory overgrowth of the synovium (pannus)

Rheumatoid arthritis , commonest

Juvenile rheumatoid arthritis (Still’s disease)

Psoriasis

Reiter’s disease

Ankylosing spondylitis

Tuberculosis.

2- Deposition of urate crystals in gout.

3- Infection: pyogenic arthritis and tuberculosis.

4- Repeated hemorrhage in hemophilia

5- Neoplastic, e.g. synovial sarcoma.


background image

Osteophytes, subchondral sclerosis and cysts

Features of osteoarthritis. A characteristic increase

in the density of subchondral bone is seen in

avascular necrosis

Alteration in the shape of the joint

: slipped

epiphysis, developmental dysplasia of the hip,

osteochondritis dissecans and avascular necrosis in

its later stages.


background image

background image

background image

Joint erosion


background image

Diagnosis of arthritis

1. Whether one or more than one joint involved?

e.g.

rheumatoid arthritis, infections and synovial tumours.

2. Which joints are involved?

Rheumatoid arthritis

Psoriatic arthritis

Gout characteristically

Osteoarthritis

Neuropathic arthritis

3. Is a known disease present?

e.g. haemophilia or

diabetes.


background image

Rheumatoid arthritis

A polyarthritis caused by inflammatory overgrowth of synovium

known as

pannus

.

The earliest change is

periarticular soft tissue swelling

and

osteoporosis

Joint space narrowing.

Initially small bony

erosions

, at the joint margins. Later, extensive

erosions

Metatarso- or metacarpophalangeal joints, proximal

interphalangeal joints and on the styloid process of the ulna.

Advance changes:

Ulnar deviation

Arthritis mutilans

.


background image

Rheumatoid arthritis

With severe disease, there may be subluxation at the

atlantoaxial joint, possibility of neurological symptoms from

compression of the spinal cord by the odontoid process

A widespread erosive arthropathy is almost diagnostic of

rheumatoid arthritis.


background image

background image

Osteoarthritis

commonest form of arthritis.

The hip and the knee are frequently involved, the ankle  elbow

are infrequently affected.

The wrist, joints of the hand and the metatarsophalangeal joint

of the big toe are also frequently involved.

Radiological features:

Joint space narrowing.

Osteophytes

Subchondral sclerosis

Subchondral cysts

Loose bodies


background image

Osteoarthritis


background image

Comparison of osteoarthritis and rheumatoid arthritis

Radiological feature

Osteoarthritis

Rheumatoid arthritis

Joint space narrowing

Maximal at weight-

bearing site

Uniform

Erosions

Not occur

Is a characteristic feature

Subchondral sclerosis

and cysts

Seen

Not a feature

Sclerosis

Prominent feature

Not a feature

Osteoporosis

Not occur

Often present

Joint involved

Knee, hip

Metacarpophalangeal

Distal interphalangeal

Metacarpophalangeal

Proximal interphalangeal


background image

Gouty Arthritis

Most commonly affects the metatarsophalangeal joint of

the big toe.

The earliest change is soft tissue swelling

Erosions have a well-defined, often sclerotic overhanging

edge

Usually no osteoporosis

Localized soft tissue lumps, known as tophi, may occur in

the periarticular and occasionally show calcification.


background image

Gouty Arthritis

Tophi


background image

Joint Infection

Pyogenic bacterial infection or tuberculosis

In pyogenic arthritis, Staphylococcus aureus, there is rapid

destruction of the articular cartilage & subchondral bone

and a soft tissue swelling. A joint effusion is the earliest

finding

TB arthritis, The hip and knee are the most commonly

affected. Joint space narrowing and erosions, articular

cortex destruction, and striking osteoporosis,


background image

pyogenic arthritis

TB arthritis


background image

Neuropathic joint (Charcot joint)

6 Ds of Charcot joint:

Increased Density (subchondral sclerosis)

Destruction

Debris (intra-articular loose bodies)

Dislocation

Distention

Disorganisation


background image

Charcot joint


background image

Avascular (aseptic) necrosis

Causes

steroid therapy

Collagen vascular diseases

Radiation therapy

Sickle cell anemia

Exposure to high pressure environments

Fractures.

The radiographic features:

Increased density of the subchondral bone with irregularity of the

articular contour or fragmentation of the bone

A characteristic crescentic lucent line just beneath the articular

cortex.

The cartilage space is preserved until secondary degenerative

changes supervene.


background image

background image

background image

Osteochondrosis

A group of disorders that affect the progress of bone

growth by bone necrosis. It is only seen in children and

adolescents who are still growing.

Perthe's disease: femora head

Freiberg’s disease: metatarsal heads

Kohler’s disease: navicular bone of the foot

Osgood–Schlatter’s disease: tibial tuberosity

Kienböck’s disease: lunate bone in the wrist


background image

Perthe's disease


background image

Perthe's disease

Kienböck’s disease


background image

Developmental dysplasia of the hip (DDH)

Abnormal development of the hip joint resulting from an

abnormal relationship of the femoral head to the

acetabulum.  There is a clear female predominance, and it

usually occurs from ligamentous laxity and abnormal position

in utero. Therefore, it is more common with oligohydramnios

pregnancies.

Risk factors include:

• female gender (M: F ratio ~1:8)
• firstborn baby
• family history
• breech presentation
• oligohydramnios


background image

Investigation used for diagnosis:

Ultrasound at early infancy

X ray later in life

The features: lateral and upper displacement

of the head of the femur. Increased slope to

the acetabular roof


background image

background image

Best Regards
