Preparation of abutment teethم .احسان فارس التكايlecture no.2
EXTENDED OCCLUSAL REST
In Kennedy Class II, modification 1, and Kennedy Class III situations in which the most posterior abutment is a mesially tipped molar, This rest should extend more than one half the mesiodistal width of the tooth.RPD totally tooth supported by means of cast retainers on all abutments
INTRACORONAL RESTIndicated only for tooth supported RPD
Advantages of internal rest seats:-
1- elimination of visible clasp
2- location of the rest seat in a more Favorable position in relation
to the tipping axis
Lingual Ball rest
Incisal RestsPrepared in form of rounded notch at incisal angle of canine or incisal edge of incisor.
Should be approximately 2.5 mm wide and 1.5 mm deep.
Notch is beveled both labially and lingually.
