Lecture 3
Dr. Hayfa’a
1
Blood flukes (Schistosomes)
Chronic schistosomiasis:
In chronic schistosomiasis, tissue injury is mediated by egg-induced granulomas
and subsequent appearance of fibrosis. About 2/3 of eggs are trapped in tissue.
Early lesion: The major pathogenic lesion is the granulomatous response
observed around eggs trapped in the tissue which contain miracidium secret
enzymatically active and immunologically stimulatory antigen (egg soluble
antigens) which lead to cellular and humoral immune responses → focal areas of
necrosis (pseudoabscess) which disappear and replaced by epitheliod cells with
giant cells surrounding the dead egg (forming pseudotubercles). Dead egg may
calcified or disappear.
Late lesion: The granulomatous process may complete heal or may progress to
fibrosis and scar formation. Accumulation of extracellular matrix (collagen) causes
the major pathologic lesion in late stage.
-
Urinary schistosomiasis (-S. haematobium)
The disease caused by S. haematobium is called bilharziasis, urinary
schistosomiasis, or endemic haematuria.
After the worms mature in the sinuosoids of the liver, they migrate from that
organ, and reach the vesical, prostatic and uterine plexuses by way of the
hemorrhoidal veins.
The eggs are deposited in the wall of bladder and lower ureters (LUT) or to a
lesser extent in the uterus, vaginal wall, prostate, rectum or other organs.
1-In acute stage , eggs invade the bladder wall and escape into lumen of the
bladder causing symptoms as terminal haematuria (is the classical presenting
feature), (s.t. complete), dysuria, frequency (nocturnal and diurnal), urgency and
dull pain in the loin and supra-pubic region. Urinary symptoms usually are not
seen for 3 to 6 months after infection and may not develop for a year or more.
Lecture 3
Dr. Hayfa’a
2
Patients with S. haematobium infection are more symptomatic than those with
intestinal schistosomiasis.
Also, the bladder wall becomes increasingly infiltered with eggs that have become
entrapped,
and
around
which
granulomas
form
(pseudoabscess
→pseudotubercle), papillomas appear. So the early stage is cellular may cause
acute obstructive uropathy and mucosal ulcers due to sloughing of mucosa.
Granulomas in the bladder wall cause bleeding, mucosal dysplasia and organ
dysfunction, particularly in the trigone region.
2-In late stage, fibrosis and thickening of the bladder wall occur. So lesions of this
stage (late) is acellular and fibrotic which called sandy patches (patchy fibrotic
thickening of badder mucosa and submucosa). Bladder wall may calcified and
defrmed.
Obstruction of the ureteral openings or of the neck of the bladder (in early or late
stage) may lead to back pressure with subsequent hydroureter and
hydronephrosis→chronic stasis of urine which predispose to calculus and UTI
(ascending bacterial infection) esp. with Salmonella. So, S. haematobium infection
may be complicated by bacteriuria, lower urinary tract infection, chronic
pylonephritis and renal failure as a late sequel.
The uterine cervix is the most common site of S. haematobium infection in
women, and granulomatous inflammation of the cervix is a common
manifestation.
In males, heavy infections may involve the urethra, prostate, seminal vesicles, and
even the spermatic cord and penis.
Genital schistosomiasis may increase the risk of acquiring HIV infection and could
predispose to cervical cancer.
Both S. haematobium and S. mansoni may invade the placenta to give rise to a
granulomatous placentitis.
Lecture 3
Dr. Hayfa’a
3
Intestinal schistosomiasis (-S. mansoni and S. japonicum)
1-Eggs of S. mansoni and S. japonicum may be deposited at any point in the
corresponding venules leading to the inferior and superior mesenteric veins
respectively.
2-In early stage, (cellular granulomatous reaction) local damage to intestial wall
caused by egg deposition and escape into the lumen of intestine and form the
dysentric type of manifestation, in which (pseudoabscess →pseudotubercle)
formation may give rise to schistosomal dysentery, accompanied by abdominal
pain, cramping, and frequent bloody or blood-flecked stools, with finding of eggs
in stool, weight loss and anemia. Also eggs that are unable to escape provoke the
formation of granulomas with patchy mucosal ulcerations.
3-in late stage: Acellular fibrotic lesion→
a- fibrosis, thickening of bowel wall and pseudotumers.
b- Adhesions to other loops of bowel and to mesentery and constrictions
secondary to the fibrosis compound the functional problems.
c- Intestinal Polyps may form from mass of eggs deposited in the submucosa,
with their surrounding granulomas, and if in the rectum may prolapse
through the anal sphincter.
d- Fibrosis of the submucosa in the areas of egg deposition explains the
decrease in egg passage in chronic infection.
Ectopic lesions
1- Hepatic schistosomiasis: Although the intestines are involved primarily in S.
mansoni and S. japonicum infections, but egg embolism (escaped mesenteric eggs
to portal veins) results in secondary involvement of the liver and form the
hepatosplenic type of manifestation, in which eggs swept back to the liver with
portal blood flow lodge in the finer branches of the portal system. Around them
granulomas and intense inflammatory reaction developed, which may lead to
periportal fibrosis if the infection is heavy enough, that may cause liver cirrhosis
(pipe stem cirrhosis).
Lecture 3
Dr. Hayfa’a
4
The main sequele of hepatic fibrosis is obstruction to portal blood flow which lead
to portal hypertesion which can cause collateral blood flow, ascites, varicies and
hematemesis due to bleeding varicies, hypersplenism (splenic reticular tissue
hyperplasia) →splenomegaly.
Hepatosplenic involvement is the most important cause of morbidity in S.
mansoni and S. japonicum infections which may present in addition to above with
anaemia,
jaundice,
thrombocytopenia,
hypergammaglobulinemia
and
hyboalbminemia. Patients may remain asymptomatic until the manifestation of
hepatic fibrosis and portal hypertension.
In hepatosplenic schistosomiasis, anemia results from:
1-bleeding. 2-hypersplenism. 3-anemia of chronic disease. 4-the ingestion of RBCs
by adult worms.
2-Pulmonary schistosomiasis: after portal hypertension caused by S. mansoni and
S. japonicum, collateral pathways shunt parasite eggs to the lungs. So, eggs may
pass through rectal, esophageal and gastric portocaval shunt into caval system,
bypassing the hepatic filter to reach the pulmonary capillary bed through the right
side of the heart → granulomatous process in the arteries and vascular
obliteration → pulmonary arterial hypertension → cor pulmonale and right heart
failure.
In S. haematobium, egg can migrate directly to lungs and induce pulmonary
inflammation.
3-Neuroschistosomiasis: result from migration of adult parasites and the
resultant entry of eggs into cerebral (S. japonicum) or vertebral venous plexus (S.
mansoni and S. haematobium)
Association of schistosomes with other diseases:
1- Salmonellosis: An association between chronic salmonellosis (persistent
salmonella bacteremia) and schistosomiasis caused by S. mansoni and S.
japonicum, has been reported from many areas,
Lecture 3
Dr. Hayfa’a
5
The organism not always S. typhi. This is called Salmonella-Schistosome
syndrome. Patients with long duration of low grade fever, Widal test positive, and
relapsed after response to treatment against Salmonella infection, but when
there is treatment for schistosomes, the fever will be relieved (without relapse).
Mechanisms of this type of association:
1-Machrophage system is impaired in some patients and Salmonella can survive
inside the macrophage.
2-The B-cell function may be depressed and the level of Abs is insufficient to
sterilize the organisms.
3-Salmonella can proliferate inside the schistosomes’ integument and intestinal
tract (service as intravascular reservoir for bacteriological relapse).
Salmonella urinary tract infection are also described with S. haematobium.
2- Hepatitis: co-infections with hepatitis B and C have been reported,which could
be due to a-immunologic response to chronic schistsomiasis may interfere with
the development of a curative immune response to hepatitis b- administration of
injectable drugs or blood transfusions used to treat schistosomiasis prior to
1980s.
3- Nephritic syndrome is occasionally seen in both S. mansoni and S.
haematobium infections.
4- Cancer: S. haematobium infection results in sequmous metaplasia of the
urinary bladder and ureter mucosa.
A clear association between chronic S. haematobium infection and squemaous
cell carcinoma of LUT has been established.
Diagnosis
1-Finding of eggs:
A-Eggs of S. haematobium in urine (rarely in stool) by:
Lecture 3
Dr. Hayfa’a
6
a- G.U.E. especially in heavy infection (direct wet preparation)
b- Concentration method either by 1-centrifugation of urine or by 2-filtration
of urine by filter with specific pores (as Whatman No. 1 filter). {early stage}.
-Midday urine specimen is used for recovery of S. haematobium eggs (the time of
peak egg excretion).
-More than one sample may be need.
-In chronic stage, no egg passed in urine.
B-Eggs of S. mansoni and S. japonicum in stool by:
a- Simple saline smear (wet preparation) in heavy infection.
b- Concentration methods (as modified formol-ether concentration method
or by filtration).
c- Kato-Katz thicksmear. It is a quantitative technique, which is recommended
because intensity of infection is associated with morbidty.
2-Egg-hatching technique: viable ova can be hatched from specimens (urine or
stool) and the diagnosis made by examining for miracidia by mixing specimen in
water and exposing them to light results in miracidia in the supernatant in few
hours.
3-Cystoscopy, proctoscopy and colonoscopy to:
a- See the morphological changes on the inner surface of the bladder or
intestine (rectum and colon) such as granulamatous and fibrotic changes
(sandy patches).
b- Recovery of eggs and examine the histopathological changes in the organ
wall by biopsy as rectal biopsy.
4-Biopsy: from the bladder wall, uterine cervix, or the vagina, in S. haematobium,
and from intestinal wall (rectal biopsy) in S. mansoni and S. japonicum, s.t. S.
haematobium for recovery of eggs, esp. in light and chronic infection (with
negative repeated urine or stool examination for egg).
5-Serological tests: CFT, FAT, IHT, LAT.
Lecture 3
Dr. Hayfa’a
7
The serological tests are important in:
1- Acute schistosomiasis because the symptoms are not specific.
2- Stool and urine negative cases especially in light infection.
3- Uncommon manifestations (as cerebral schistosomiasis).
6-Dtection and quantification of schistosomal antigens in serum and urine.
-can identify patients with active infection (important in endemic areas)
-The sensitivity of this test decreased in light infection.
-This test is used in monitoring the efficacy of schistosome chemotherapy.
7-PCR (polymerase chain reaction).
8-Aldehyde test: positive due to high serum globulins (hypergammalobulinemia).
9-Intradermal skin test (schistosomian skin test): become positive after few
months of infection.
Epidemiology
-The disease (contact with fresh water)
1-Higher in rural area (agricultural population).
2-Sex: more in males than in females (occupational hazard).
3-More common in lower socio-economic communities(pathing and washing
clothes).
4-Infection may last years.
-The reservoir host
1-S. haematobium: humans are the only important host.
2-S. mansoni: humans are apparently the only important host, but rodents may
carry infection in some areas.
3-S. japonicum: many domestic animals (cats, dogs, cattles, horses and pigs) as
well as some wild animals.
-The intermediate host
1-S. haematobium and S. mansoni: aquatic snails
2- S. japonicum: amphibious (semiaquatic) snails.
Lecture 3
Dr. Hayfa’a
8
Control and prevention of schistosomiasis
1-Education of people in endemic areas.
2-Proper disposal of urie and feces.
3-Snail control (chemical and biological eradication).
4-Treatment of infected persons.
It is difficult to control schistosomiasis because:
1- The intermediate host (snail) is diffecult to killed by any chemical or
biological agents.
2- In some species (S. japonicum), the snails are amphibious (semiaquatic). So,
eradication of snails from water is virtually useless.
3- Some species (S. japonicum) have wide range of reservoir hosts (domestic
and wild). So, treatment of human cases is virtually useless.
The easiest one to control is S. haematobium because:
1- Snails are aquatic.
2- Lack of reservoir hosts.
